Yo Power Intelligent Pure Sine Wave Power Inverter 1000W 12V 220V
The power inverter 1000W is an high frequency inverter. It works for 12V battery system and converter battery power to 220VAC pure AC power for a variety of electric equipment, such as mobile phone, computer, incandescent lamp, electric fans, water dispensers, coffee cooker, induction cooker etc.
This is a pure sine wave type of inverter, which means that the AC output harmonically follows a smooth sine wave and is almost identical to normal mains electricity. Pure sine waveform output is more superior and efficiency than modified sine waveform output.
The inverter also features a powerful USB port for faster charging of mobile phones, MP3 players and others mobile loads
1. Features
-
The power inverter 1000W is built-in intelligent temperature-controlled fan. The internal temperature is higher, the speed of the fan is faster;
-
High-quality fine copper inductance, double loop bank winding output inductance, which can ensure the output voltage wave shape
-
Unique front and back double soft start technology
-
Core of CUP and the pulse width control technology of SPWM
-
Special constant power technology
-
Multiple protection function, such as over load protection, over current protection, high temperature protection, short circuit protection, the battery reverse connect protection, battery over voltage and under voltage protetion, inbuild fuse and so on
-
100% pure sine waveform output, low distortion, low noise, strong load capacity and so on
-
Buzzer alarm to remind when the 300W power inverter in failure status
-
Dual AC outlets and one USB socket
-
2 years warranty
2. Parameters
| Model |
YQHI-1000W |
| Rated power |
1000W |
| Rated system voltage |
12V |
| Peak power |
2000W |
| Output voltage |
220VAC |
| Phase |
Single-phase |
| Inverter efficiency |
>90% |
| Stand by consumption |
<10W |
| Wave form |
Pure Sine Wave |
| LED display |
LED display power&fail status |
| USB socket |
Yes, 5V |
| Fuse |
35A
|
| Low voltage alarm |
10.5V±0.3V |
| Low voltage disconnect |
10V±0.5V |
| Over voltage disconnect |
15.5V±0.5V |
| Over load disconnect |
1200W (10S) |
| Over temperature disconnect |
>75 ℃ |
| Ambient temperature |
-10℃~50℃ |
| Dimension (mm) |
305*146*66 |
| N.W (KG) |
2.8 |
| Packing size (mm) |
360*185*115 |
| G.W (KG) |
3.5 |
| Warranty |
2 years |
3. Application
All power system with battery
4. Package information
1pcs 1000W power inverter
1pcs user manual
1pcs connector
